Drum filter TF

The drum filter TFB is used for the filtration of large air volumes in a wide variety of air filtration systems. The material settles on the filter medium and is continuously extracted via nozzles. Diameter, length, filter medium and more details are designed according to the application and the conditions on site. Optionally, an integrated pre-filter unit (TFC) can be added for high material contents in the air stream.



  • Flow from inside to outside
  • high separation efficiency due to high quality filter medi
  • no pressure fluctuations in the system
  • Air volumes up to 130,000 m³/h
  • Temperatures up to 180°C
  • Filter quality up to F7
  • Cleaning air volume: max. 4.000 m³/h cleaning air volume: max. 1.000 m³/h


  • Pressurization available
  • ATEX version available
  • Integrated pre-filter unit (TFC)
  • Housing chamber


  • Standard steel, painted
  • Galvanized steel

Main areas of application:

  • Non-Woven Industry
  • Textile industry
  • Glass fiber industry
  • Woodworking industry
  • Paper industry
  • Hygienic products
  • Automobile
